• Cechy szczególne
  ASRock Super Alloy
  - XXL Aluminum Alloy Heatsink
  - Premium 45A Power Choke
  - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)
  - I/O Armor
  - Sapphire Black PCB
  - High Density Glass Fabric PCB
  - 2oz Copper PCB
  ASRock Steel Slots
  ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3)
  ASRock Full Spike Protection (for all USB, Audio, LAN Ports)
  ASRock Live Update & APP Shop
• CPU
  - Supports AMD Socket AM4 A-Series APUs (Bristol Ridge) and Ryzen Series CPUs (Vermeer, Cezanne, Renoir, Summit Ridge, Raven Ridge and Pinnacle Ridge)*
  - 12 Power Phase design



  *Bristol Ridge does not supports since BIOS version 7.XX.
  Vermeer, Cezanne and Renoir CPUs are supported after updating the BIOS, using another CPU for that update.
• Chipset
  - AMD Promontory X370
• Pamięć
  - Dual Channel DDR4 Memory Technology
  - 4 x DDR4 DIMM Slots
  - AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 2933+(OC) / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory*
  - AMD Ryzen series CPUs (Summit Ridge) support DDR4 2933+(OC) / 2933(OC) / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory*
  - AMD Ryzen series CPUs (Raven Ridge) support DDR4 2933 / 2667 / 2400 / 2133 non-ECC, un-buffered memory*
  - AMD 7th Gen A-Series APUs support DDR4 2400 / 2133 ECC & non-ECC, un-buffered memory*
  - Max. capacity of system memory: 64GB*
  - 15μ Gold Contact in DIMM Slots



  *Dla Procesorów Serii Ryzen (Raven Ridge), ECC wspierane jest tylko przez procesory PRO CPU.
  Prosimy o sprawdzenie w poniższej tabeli obsługę maksymalnej częstotliwości dla DDR4 UDIMM.

  A-Series APUs:


  Ryzen Series CPUs (Matisse):


  Ryzen Series CPUs (Pinnacle Ridge):


  Ryzen Series CPUs (Picasso):


  Ryzen Series CPUs (Summit Ridge):


  Ryzen Series CPUs (Raven Ridge):


  SR: Single rank DIMM, 1Rx4 or 1Rx8 on DIMM module label
  DR: Dual rank DIMM, 2Rx4 or 2Rx8 on DIMM module label

  **Z powodu ograniczeń system operacyjnego, rzeczywisty rozmiar pamięci może być mniejszy niż 4GB dla rezerwacji przez system Windows^® 32-bit. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS
  - 128Mb AMI UEFI Legal BIOS with GUI support
  - Supports "Plug and Play"
  - ACPI 5.1 compliance wake up events
  - Supports jumperfree
  - SMBIOS 2.3 support
  - CPU, VCORE_NB, DRAM, VPPM, PCH 1.05V, +1.8V, VDDP, PROM 2.5V, Voltage Multi-adjustment
• Karta graficzna
  - Integrated AMD Radeon™ Vega Series Graphics in Ryzen Series APU*
  - Zintegrowana Grafika AMD Radeon™ R-Series w APU serii-A*
  - DirectX 12, Pixel Shader 5.0
  - Domyślna ilość współdzielonej pamięci to 2GB. Maksymalna ilość współdzielonej pamięci to 16GB.**
  - Supports HDMI with max. Rozdzielczośćup to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz
  - Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
  - Supports HDCP 1.4 with HDMI Port
  - Supports Full HD 1080p Blu-ray (BD) playback with HDMI Port



  *Wsparcie może się różnić w zależności od CPU

  **Maksymalna współdzielona pamięć 16GB wymaga 32GB pamięci w systemie.
• Audio
  - 7.1 CH HD Audio with Ochrona Treści (Realtek ALC892 Audio Codec)
  - Premium Blu-ray Audio support
  - Supports Surge Protection
  - Nichicon Fine Gold Series Audio Caps
  - PCB Isolate Shielding
  - Individual PCB Layers for R/L Audio Channel
• LAN
  - Gigabit LAN 10/100/1000 Mb/s
  - GigaLAN Intel^® I211AT
  - Supports Wake-On-LAN
  - Supports Lightning/ESD Protection
  - Supports Energy Efficient Ethernet 802.3az
  - Supports PXE
• Sloty
  AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge)
  - 2 x PCI Express 3.0 x16 Slots (single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE4))*
  AMD 7th A-Series APUs
  - 1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE2))*
  AMD Ryzen series CPUs (Raven Ridge)
  - 1 x PCI Express 3.0 x16 Slot (single at x8 (PCIE2))*
  AMD Athlon series CPUs
  - 1 x PCI Express 3.0 x16 Slot (single at x4 (PCIE2))*

  - 4 x PCI Express 2.0 x1 Slots
  - Supports AMD Quad CrossFireX™ and CrossFireX™**
  - Supports NVIDIA^® Quad SLI™ and SLI™**
  - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
  - 15μ Gold Contact in VGA PCIe Slot (PCIE2)



  *Obsługa bootowania z dysków NVMe SSD

  **Ta opcja obsługiwana jest tylko z procesorami serii Ryzen (Matisse, Summit Ridge and Pinnacle Ridge).
• Magazynowanie
  - 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
  - 1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Matisse, Picasso, Summit Ridge, Raven Ridge and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with A-Series APU and Athlon series APU)*
  - 1 x M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen2 x2 (10 Gb/s)*



  *Obsługa bootowania z dysków NVMe SSD
  Supports ASRock U.2 Kit
• Złącza
  - 1 x COM Port Header
  - 1 x TPM Header
  - 1 x Power LED and Speaker Header
  - 1 x AMD Fan LED Header*
  - 2 x RGB LED Headers*
  - 1 x CPU Fan Connector (4-pin)**
  - 1 x CPU Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
  - 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
  - 1 x Chassis Optional/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
  - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
  - 1 x Front Panel Audio Connector
  - 1 x AMD LED Fan USB Header
  - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
  - 2 x USB 3.1 Gen1 Headers (Support 4 USB 3.1 Gen1 ports) (Supports ESD Protection)



  *Obsługa Paska LED aż do 12V/3A, 36W
  Header AMD Fan LED obsługuje paski LEDowe o maksymalnej mocy 3A (36W) oraz długości do 2.5M.

  **The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.

  ***The CPU Optional/Water Pump Fan supports the water cooler fan of maximum 1.5A (18W) fan power.

  ****Obudowa Opcja/Złącze Pompy Wody obługuje wentylatory o maksymalnej mocy 1.5A (18W).
  CHA_FAN2 can auto detect if 3-pin or 4-pin fan is in use.
• Tylny panel
  - 2 x Antenna Ports
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x HDMI Port
  - 1 x Optical SPDIF Out Port
  - 1 x USB 3.1 Gen1 Type-A Port (Supports ESD Protection)
  - 1 x USB 3.1 Gen1 Type-C Port (Supports ESD Protection)
  - 6 x USB 3.1 Gen1 Ports (Supports ESD Protection)
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
• Oprogramowanie i UEFI
  Software
  - ASRock A-Tuning
  - ASRock RGB LED
  - ASRock APP Charger
  UEFI
  - ASRock Full HD UEFI
  - ASRock Funkcja Instant Flash
  - ASRock Easy RAID Installer



  *Te narzędzia można pobrać z Live Update & APP Shop.
• Akcesoria
  - I/O Shield
  - 2 x SATA Data Cables
  - 1 x ASRock SLI_HB_Bridge_2S Card
  - 3 x Screws for M.2 Sockets
• Hardware Monitor
  - Temperature Sensing: CPU, CPU Optional/Water Pump, Chassis, Chassis Optional/Water Pump Fans
  - Fan Tachometer: CPU, CPU Optional/Water Pump, Chassis, Chassis Optional/Water Pump Fans
  - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU Optional/Water Pump, Chassis, Chassis Optional/Water Pump Fans
  - Fan Multi-Speed Control: CPU, CPU Optional/Water Pump, Chassis, Chassis Optional/Water Pump Fans
  - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, VCORE_NB, DRAM, PCH 1.05V, +1.8V, VDDP
• Wymiary
  - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
• System operacyjny
  - Microsoft^® Windows^® 10 64-bit / 11 64-bit*



  *Bristol Ridge and Summit Ridge do not officially support Windows^® 11.
• Certyfikaty
  - FCC, CE
  - ErP/EuP ready (ErP/EuP ready power supply is required)

* This product has reached EOL (End of Life) and was discontinued in 2020/Jul. Technical and security-related support will continue for up to 6 years after EOL, subject to supplier support availability.
