Intel® Core™ i7 / i5 / i3 Mobile Processor Family
Intel® HD Graphics, Support Native Full HD 1080p Playback
BD (Blu-ray Disc) Combo
7.1 CH HD Audio
MCE Remote Controller
802.11n Wireless Networking (300Mbps)
2 x USB 3.1 Gen1
Supports ASRock XFast USB, XFast LAN Technologies
This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.
- Intel® Core™ i7 / i5 / i3 Mobile Processor Family
- 2 x DDR3 SO-DIMM slots, 4GB per DIMM (Max. 8GB*) - Support dual channel DDR3 1066MHz
*Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.
- Mobile Intel® HM55 Express chipset
*Due to Windows® XP and PCH chipset (HM55) limitations, if you use Windows® XP, please disable the BIOS option "USB2.0 Rate Matching Hub" to make USB devices work properly. (For example, in the process of installing Windows® XP or using USB3.0 devices.)
- Intel® HD Graphics*
*Due to chipset limitation, the Blu-ray playback of Intel® HD Graphics is only supported under Windows® Vista™ and Windows® 7.
- 7.1 CH HD Audio
- 2.5" HDD, support second 2.5" HDD
- BD Combo
- Gigabit LAN
- 802.11b/g/n wireless LAN*
- 2 x USB 3.1 Gen1, 1 x MIC, 1 x Headphone
- 1 x HDMI, 1 x D-Sub VGA, 6 x USB 2.0, 1 x S/PDIF, 1 x eSATAII*
*For eSATA function, Hot Plug function is supported in AHCI mode only. IDE mode does not support Hot Plug function.
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
