Product Photo
  • Product Thumbnail 1
OCWorkbench - Product Excellence


  • Socket 754 for AMD Athlon™ 64 and Sempron processors
  • ULi® M1697
  • Chipset capable to FSB 1000 MHz (2.0 GT/s), Hyper-Transport Technology, AMD Cool 'n' Quiet Technology
  • 1 x Future CPU Port (Supports CPU upgrade from AMD K8 754-Pin CPU to K8 939-Pin CPU or AM2 940-Pin CPU through 939CPU Board or AM2 CPU Board)
  • Untied Overclocking : During Overclocking, FSB enjoys better margin due to fixed PCIE/ PCI Buses
  • Supports DDR400, 2 DIMMs slots
  • Hybrid Booster - ASRock Safe Overclocking Technology
  • PCI Express x16 slot for VGA interface - PCI Express x8 slot, to adopt 2nd PCI Express x16 VGA card and other PCI Express x4, x2, x1 interface cards - PCI Express x1 slot
  • 4 ports of SATA2 3.0Gb/s, RAID 0, 1, 0+1, JBOD and RAID 5, and Hot Plug functions, and 2 ATA 133 IDE ports
  • 2 ports of eSATA2 3.0Gb/s (shared with 2 SATA2 ports), support Hot Plug function
  • 5.1 Channel High Definition Audio, 10/100 Ethernet LAN
  • Windows® Vista Hardware Ready
  • ASRock eSATA2 I/O : 2 eSATA2 Ports, 4 ready-to-use USB 2.0 ports
