A PCIe x4 add on card that provides a Type-A USB 3.1 port plus another Type-C USB 3.1 port for delivering up to 10Gb/s data transfer rates. Compatible with motherboards that have PCIe x4/8/16 (@x2) slots.
Faster device charging with power currents of 3.0 ampere
Ultra durable
supports over 10,000 plug and removals
A reversible design
that fits the connector either way

Specifications

 General
Platform- Size: 3.1-in x 3.2-in, 7.9 cm x 8.1 cm
Controller- ASMedia ASM1142 Controller
PCIE- PCI Express x4 Connector (x2 lane)
- Compliant with PCI Express 1.1, 2.0 and 3.0 specifications
- Supports data rates up to 10 Gbps
- Compliant with x4, x8 or x16 PCI Express Slots
Connector- 1 x USB 3.1 Type-A Port (Supports ESD Protection (ASRock Full Spike Protection))*
- 1 x USB 3.1 Type-C Port (Supports ESD Protection (ASRock Full Spike Protection))**

*For charging Type-A USB devices, we suggest using the Type-A connectors on your motherboard.

**This port supports power outputs up to 5V/3A. For charging Type-C USB devices, the device should support Type-C standards to adjust the current because it will be different in Power On state (3 Amp) and Sleep state (1 Amp).

***Some Type-C USB devices may only be charged by its own adapter.

OS- Microsoft® Windows® 10 32-bit / 64-bit / 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
