• CPU
  - Support up to 95W Socket AM2+* / AM2 processors: AMD Phenom™ FX / Phenom / Athlon 64 FX / Athlon 64 X2 Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron processor
  - Support up to 95W Socket AM3 processors*: AMD Phenom™ II X6 / X4 / X3 / X2 / Athlon II X4 / X3 / X2 / Sempron processors
  - Supports UCC feature (Unlock CPU Core)
  - Supports AMD's Cool 'n' Quiet Technology
  - FSB 1000 MHz (2.0 GT/s)
  - Supports Untied Overclocking Technology
  - Supports Hyper-Transport Technology



  *If you use AM3 / AM2+ CPU on AM2 chipset motherboard, the system bus speed will downgrade from HT3.0 (5200 MT/s) to HT1.0 (2000 MT/s), but the CPU frequency will not be influenced.

  **For more information, please refer to the "CPU Support List".
• Chipset
  - NVIDIA^® GeForce 7025 / nForce 630a
• Memory
  - Dual Channel DDR2 memory technology
  - 2 x DDR2 DIMM slots
  - Supports DDR2 1066*/800/667/533 non-ECC, un-buffered memory
  - Max. capacity of system memory: 8GB**



  *Support with AM3 / AM2+ CPU.

  **Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
• BIOS
  - 4Mb AMI Legal BIOS
  - Supports "Plug and Play"
  - ACPI 1.1 Compliance Wake Up Events
  - Supports jumperfree
  - SMBIOS 2.3.1 Support
  - Supports Smart BIOS
• Graphics
  - Integrated NVIDIA^® GeForce 7025 graphics
  - DX9.0 VGA, Pixel Shader 3.0
  - Max. shared memory 256MB
  - Supports D-Sub with max. resolution up to 1920x1440 @ 60Hz
• Audio
  - 5.1 CH HD Audio (VIA^® VT1708S / VT1705 Audio Codec)
• LAN
  - Realtek PHY RTL8201EL / 8201CL
  - Speed: 10/100 Ethernet
  - Supports Wake-On-LAN
  - Supports PXE
• Slots
  - 1 x PCI Express x16 slot
  - 1 x PCI Express x1 slot
  - 2 x PCI slots
• Connector
  - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1, RAID 5 and JBOD), NCQ and Hot Plug functions
  - 1 x ATA133 IDE connector (supports 2 x IDE devices)
  - 1 x Floppy connector
  - 1 x Print port header
  - CPU/Chassis FAN connector
  - 24 pin ATX power connector
  - 4 pin 12V power connector
  - Front panel audio connector
  - 2 x USB 2.0 headers (support 4 USB 2.0 ports)



  *This mainboard does not support RAID with HDDs of 3TB and above.
• Rear Panel I/O
  I/O Panel
  - 1 x PS/2 Mouse Port
  - 1 x PS/2 Keyboard Port
  - 1 x Serial Port: COM1
  - 1 x VGA Port
  - 4 x Ready-to-Use USB 2.0 Ports
  - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  - HD Audio Jack: Line in / Front Speaker / Microphone
• Unique Feature
  - ASRock OC Tuner
  - Intelligent Energy Saver
  - Instant Boot
  - ASRock Instant Flash
  - ASRock OC DNA
  - Hybrid Booster:
  - CPU Frequency Stepless Control
  - ASRock U-COP
  - Boot Failure Guard (B.F.G.)
  - ASRock AM2 Boost: ASRock Patented Technology to boost memory performance up to 12.5%
• Support CD
  - Drivers, Utilities, AntiVirus Software (Trial Version), ASRock Software Suite (CyberLink DVD Suite and Creative Sound Blaster X-Fi MB) (OEM and Trial Version)
• Accessories
  - Quick Installation Guide, Support CD, I/O Shield
  - 2 x SATA Data Cables
• Hardware Monitor
  - CPU Temperature Sensing
  - Chassis Temperature Sensing
  - CPU Fan Tachometer
  - Chassis Fan Tachometer
  - CPU Quiet Fan
  - Voltage Monitoring: +12V, +5V, +3.3V, Vcore
• Form Factor
  - Micro ATX Form Factor: 9.6-in x 7.0-in, 24.4 cm x 17.8 cm
• OS
  - Microsoft^® Windows^® 7 / 7 64-bit / Vista™ / Vista™ 64-bit / XP / XP 64-bit compliant
• Certifications
  - FCC, CE

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

The above user interface picture is a sample for reference. The actual user interface may vary with the updated software version.
