P4i45GV R5.0

  1. Socket 478 for Intel® P4 processor
  2. Intel® 845GV chipset
  3. Worldwide Patent - ASRock A.G.I. 8X A gift for VGA upgrade on i845GV
  4. FSB 533/400MHz, DDR 333/266
  5. Supports Hyper-Threading Technology
  6. Integrated Intel® Extreme Graphics
  7. ASROCK I/O - default 4 ready-to-use USB 2.0 ports on rear panel, default Game/MIDI port.
  8. 5.1 Channel audio.
  9. default 10/100 Ethernet PCI LAN.
  10. Multi-languages Quick Installation Guide.
  11. Bundle CD includes Anti Virus Software, ASRock PC DIY Live Demo, Audio Player, etc..
This model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.

Product Specifications

CPU- Socket 478, Intel® Pentium® 4(Northwood/Prescott)/Celeron
- FSB 533/400 MHz
Chipset- Intel® 845GV, Supports Hyper-Threading Technology
Memory- 2 x DDR slots, DDR333/266 non-ECC, un-buffered memory
- Max. capacity of system memory: 2GB
 Audio, Video and Networking
Graphics- Int. Intel® Extreme Graphics
- Memory Max. 64MB
Audio- Chip AC97 CODEC
- Channel 5.1 CH
LAN- 802.3u, 10/100 Ethernet PCI LAN, WOL supported
- Supports PXE
 Expansion / Connectivity
Slots- 3 PCI slots, PCI 2.2
- AMR 1 slots
Connector- ASRock A.G.I. 8X - VGA upgrade slot, (AGP8X/4X compatible)
- IDE 2 x ATA 100/66/33
- Floppy 1 connector
- SIR/CIR 1/0
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- IDE LED connector
- CD/AUX/ audio in
- Front panel audio connector
- 1 x USB 2.0 connector supports additional 2 USB 2.0 ports
Rear Panel I/OASROCK I/O
- PS2 Keyboard x1
- PS2 Mouse x1
- USB2.0 4 ports default on rear panel + 2 ports upgrade via header
- Parallel x1
- Game/MIDI x1
- LAN port RJ45 x1
- Audio I/O Line In/Line Out/Mic.
- VGA x1
 Other Features / Miscellaneous
Unique FeatureHybrid Booster:
- CPU Frequency Stepless control
- ASRock U-COP
- Boot Failure Guard (B.F.G)
- AGP/PCI frequency control
Support CD- Drivers
- Bundle CD includes: Anti Virus Software, ASRock PC DIY Live Demo, Audio Player, etc..
Accessories- Quick Installation Guide
- Support CD
- Floppy/ATA 100 Cables
- 1x COM Port Bracket
Form Factor- Micro ATX
OS- Microsoft® Windows® 98SE/ME/2000/XP compliant
Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS or using the third-party overclocking tools. Overclocking may affect your system stability, or even cause damage to the components and devices of your system. It should be done at your own risk and expense. We are not responsible for possible damage caused by overclocking.

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
